Ingestion Pipelines

An ingestion pipeline is how Agentcy turns an external system into graph knowledge. A pipeline runs one or more connectors, normalizes their output into Neo4j nodes and edges, and schedules incremental resyncs. Pipelines are versioned, reversible, and observable.

Related concepts:

• Connectors & Tool Providers — what a connector is.
• Knowledge Graph & Realms — where pipeline output lands.
• Tasks, Workers & Workflows — how pipelines actually execute.

Anatomy of a pipeline

┌─────────────────────────────────────────────────────────────┐
│  Pipeline: "infra-weekly"                                    │
│  realm: infrastructure    schedule: 0 */6 * * *              │
│                                                              │
│  ┌──────────────┐   ┌──────────────┐   ┌──────────────────┐  │
│  │ GitHub       │   │ Kubernetes   │   │ AWS (us-east-1)  │  │
│  │ repos, PRs,  │   │ pods, deploys│   │ EC2, S3, IAM     │  │
│  │ branches     │   │ services     │   │ CloudWatch       │  │
│  └──────┬───────┘   └──────┬───────┘   └────────┬─────────┘  │
│         │                  │                    │            │
│         └────── normalize & dedupe ─────────────┘            │
│                           │                                  │
│                           ▼                                  │
│              Neo4j (realm=infrastructure)                    │
└─────────────────────────────────────────────────────────────┘

Each pipeline has:

• A name (unique per org).
• A target realm — all nodes written get realm = "<value>" so queries can be scoped.
• One or more steps — each step runs a connector with its own config.
• A schedule — cron expression or manual.
• A retention policy — how long to keep superseded nodes before prune.

Lifecycle

┌─────────┐  validate    ┌─────────┐   run   ┌──────────┐  finalize  ┌──────────┐
│  draft  │─────────────▶│  ready  │────────▶│  running │────────────▶│  synced  │
└─────────┘              └─────────┘         └─────┬────┘             └──────────┘
                                                   │ error
                                                   ▼
                                             ┌──────────┐
                                             │  failed  │──► revert to previous run
                                             └──────────┘

• validate — every connector step runs validate_config (credentials, scopes, reachability). Invalid configs never get to ready.
• running — a worker claims the run. Each step produces a batch of nodes + edges, streamed to agentcy-graph in transactions sized by PIPELINE_BATCH_SIZE.
• finalize — after all steps succeed, the previous snapshot is superseded. Orphan nodes (present in the previous run, absent now) are soft-deleted (archived_at set).
• failed — nothing is published. The previous snapshot stays current. Retry or revert from the UI.

Incremental vs. full sync

Every connector declares which it supports. Most support both.

• Full sync — re-reads everything. Slower, catches drift (renames, deletions).
• Incremental sync — uses provider deltas (GitHub since, K8s resource versions, etc.). Fast; default for scheduled runs.

The first run of a pipeline is always full. Scheduled runs are incremental unless you request a full sync from the UI or pass {"mode":"full"} to the run endpoint.

Realms prevent collision

Multiple pipelines can write to the same Neo4j database safely because every node and edge carries a realm property. Queries filter by realm (or * to cross-search). A pipeline writing to design cannot clobber a node written by the infrastructure pipeline — even if the source_id matches — because realm is part of the primary key.

See Knowledge Graph & Realms.

Wire a pipeline

Minimum viable pipeline over the REST API:

curl -X POST http://localhost:8080/api/v1/pipelines \
  -H "authorization: Bearer $TOKEN" -H 'content-type: application/json' \
  -d '{
    "name": "github-weekly",
    "realm": "development",
    "schedule": "0 3 * * 1",
    "steps": [{
      "connector": "github",
      "source_id": "gh-primary",
      "mode": "incremental"
    }]
  }'

Trigger a run:

curl -X POST http://localhost:8080/api/v1/pipelines/$PIPELINE_ID/runs \
  -H "authorization: Bearer $TOKEN"

Stream run events (SSE) — the UI uses this for live status:

curl -N http://localhost:8080/api/v1/pipelines/$PIPELINE_ID/runs/$RUN_ID/events \
  -H "authorization: Bearer $TOKEN"

Running without a pipeline

For one-off syncs you don't need a pipeline. POST /api/v1/sources/:id/sync runs a single connector inline (or enqueues if workers is enabled). That path is how the Connectors UI's Sync button works.

Pipelines exist when you need:

• multi-step ingestion that must succeed atomically,
• scheduling with retention + revert,
• reporting ("what changed in the last run?"),
• a named configuration that other teams can subscribe to.

Observability

For every run you get:

• started_at, finished_at, status.
• Per-step counts: nodes_created, nodes_updated, nodes_archived, edges_created, errors.
• A diff against the previous successful run.
• Full tracing logs (filter by run_id).

The Activity feed (GET /api/v1/activity) includes one entry per run state change, so audit + operational dashboards share the same event stream.

Failure modes and retries

Failure	Behavior
Auth error on a step	Run marked failed, no writes committed. Validate the source config.
Rate-limit from provider	Exponential backoff, up to PIPELINE_STEP_MAX_RETRIES (default 5).
Neo4j write timeout	Batch retries; if repeated, run fails. Next run retries from scratch.
Worker crash mid-run	Redis lease expires after WORKER_LEASE_TTL (default 300s). Another worker picks up.
Provider returns partial data	Succeeds; archived_at is not applied to missing nodes (safety rail). Requires a full sync to prune.

Revert

Every successful run creates a snapshot. Revert re-applies the previous snapshot as the current one — useful when a provider fed bad data (e.g. a GitHub rename made half the repos disappear).

curl -X POST http://localhost:8080/api/v1/pipelines/$PIPELINE_ID/runs/$RUN_ID/revert \
  -H "authorization: Bearer $TOKEN"

Revert is recorded as a new run with mode: "revert" so it shows in history.

Under the hood

• Pipelines are stored in Postgres (pipelines, pipeline_runs, pipeline_step_results).
• Steps run through agentcy-ingest::PipelineRunner, which calls ConnectorToolProvider::ingest on each source.
• Graph writes go through agentcy-graph::RealmWriter, which enforces the realm property and primary-key composition.
• The ConnectorEventBus fan-outs progress events to the UI over WebSocket.

Next

• How-To: Scheduled Tasks — scheduling agent runs (distinct from pipelines).
• Connectors Overview — the 26 sources available.
• Tasks, Workers & Workflows — where runs actually execute.
